Pin Assignments (M Versions)
01/01
Z3
E = Input, A = Output, M = Ground
F = X60001 9 Pins, black
G = X60002 24 Pins, black
H = X60003 52 Pins, black
I = X60004 40 Pins, black
J = X60005 9 Pins, black
X60001
Pin Type Signal Description/Function Connection
1 A 15 Activate relay Relay, injection valves
2 A P_DKSM+ Voltage supply Electric throttle motor
3 Not used
4 M 31E Ground Ground point
5 M 31L Ground Ground point
6 M 31L Ground Ground point
7 E 30 Voltage supply B+ junction point E-box
8 E U_HR<2 Voltage supply Fuse holder in E-box, fuse F202
9 M P_DKSM– Ground Electric throttle motor
X60002
Pin Type Signal Description/Function Connection
1 M T_LHV1 Oxygen sensor heating ground Oxygen sensor 1 (in front of
catalytic converter)
2 Not used
3 Not used
4 Not used
5 M M_CAN Ground Oxygen sensors, exhaust
temperature sensor
6 Not used
7 M T_LHH1 Oxygen sensor heating ground Oxygen sensor 1 (behind catalytic
converter)
8 Not used
