BMW Z3(E36/7) - Pin Assignments (Z3 Versions); X60001; X60002

BMW
BMW
BMWBMW
1210.26Ća
2001
Pin Assignments (Z3 Versions)
01/01
Z3
E = Input, A = Output, M = Ground
A = X60001 9 Pins, black
B = X60002 24 Pins, black
C = X60003 52 Pins, black
D = X60004 40 Pins, black
E = X60005 9 Pins, black
X60001
Pin Type Signal Description/Function Connection
1 A 15 Activate relay Relay, injection valves
2 Not used
3 Not used
4 M 31E Ground Ground point
5 M 31L Ground Ground point
6 M 31L Ground Ground point
7 E 30 Voltage supply B+ junction point E-box
8 E U_HR<2 Voltage supply Fuse holder in E-box, fuse F202
9 Not used
X60002
Pin Type Signal Description/Function Connection
1 M T_LHV1 Oxygen sensor heating ground Oxygen sensor 1 (in front of
catalytic converter)
2 Not used
3 E/A D_CAN-L CAN bus low Transmission control module (EGS)
4 E/A D_CAN-H CAN bus high Transmission control module (EGS)
5 Not used
6 E/A D_TXD2 Diagnosis Transmission control module (EGS)
7 M T_LHH1 Oxygen sensor heating ground Oxygen sensor 1 (behind catalytic
converter)
8 Not used
