BMW Z3(E36/7) - Fuses 5, 6, 7, and 8

.35 RT/GN
.5 RT/GN
Z3 COUPE
BM
BMW
BMWBMW
Z3
FUSES 5, 6, 7, AND 8
0670.3Ć
2001
01
FUSE DETAILS
P90
FRONT POWER
DISTRIBUTION BOX
K2
HORN RELAY
6 X56
16
1 RT/WS/GE
6133.0
30
X10015
01/01
14
X1234
S47
DRIVER’S DOOR
LOCK SWITCH
.5 RT/GN
M12
DRIVER’S DOOR
LOCK MOTOR
6 X660
.5 RT/GN
M13
PASSENGER’S
DOOR LOCK
MOTOR
6 X641
.5 RT/GN
S49
PASSENGER’S
DOOR LOCK
SWITCH
2 X742
.35 RT/GN
M17
LUGGAGE
COMPARTMENT
LOCK MOTOR
X311
2 X747
11 12 X257 12
.35 RT/GN .35 RT/GN .35 RT/GN
.75 RT/GN
5126.0
11 X256
.5 RT/GN
5126.0
5126.0
3
5126.0
5126.0
F7
5A
13 X279
10
S56
PASSENGER’S
SEAT, SEAT
CONTROL SWITCH
2.5 RT/SW
5200.0
F5
30A
6 X63
12
K9
UNLOADER RELAY,
TERMINAL 15
2.5 RT/BR
6424.0
F6
20A
F8
15A
2 RT/SW
R33
STEERING ANGLE
SENSOR
X1658
3452.1
1
.5 RT/GN
WITH DSC
3452.2
6575.0 6575.0 6575.0
6575.06575.0
2 X13139
A194y
REMOTE CONTROL
MODULE
6610.2
WITH DWA
.5 RT/GN
