BMW Z3(E36/7) - X70004

BMW
BMW
BMWBMW
2460.14Ćc
2001
Pin Assignments
01/01
Z3
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionSignalType
44 Not used
45 Not used
46 Not used
47 Not used
48 Not used
49 Not used
50 Not used
51 Not used
52 Not used
X70004
Pin Type Signal Description/Function Connection
1 E S_GL2 Gear range signal L2 Transmission valve unit
2 A U_GETRPO Voltage supply, gear range switch Transmission valve unit
3 A U_EDSMV2 Voltage supply, solenoid valves Transmission valve unit
4 A S_RFLREL Activate relais Relais, back up lights
5 Not used
6 A T_EDSWK Torque converter clutch solenoid
valve control
Transmission valve unit
7 Not used
8 A T_EDS1 Hydraulic pressure regulator control Transmission valve unit
9 A S_MV3 Solenoid valve 3 control Transmission valve unit
10 A S_MV2 Solenoid valve 2 control Transmission valve unit
11 A V_EDSMV1 Voltage solenoid valves Transmission valve unit
12 Not used
13 Not used
14 E S_GL3 Gear range signal L3 Transmission valve unit
15 E S_GL4 Gear range signal L4 Transmission valve unit
16 E S_GL5 Gear range signal L5 Transmission valve unit
17 E S_GL1 Gear range signal L1 Transmission valve unit
18 A A_TOELG Oil temperature signal + Transmission valve unit
