BMW Z3(E36/7) - Pin Assignments (Z3 Versions Early Prod. and M Versions); X1746

BMW
BMW
BMWBMW
3452.1Ća
2001
Pin Assignments (Z3 Versions Early Prod. and M Versions)
01/01
Z3
E = Input, A = Output, M = Ground
X1746
Pin Type Signal Description/Function Connection
1 M GND Ground Ground point
2 M FL0 Sensor ground Left front speed sensor (ABS)
3 E FL1 Speed signal Left front speed sensor (ABS)
4 Not used
5 M RR0 Sensor ground Right rear speed sensor (ABS)
6 E RR1 Speed signal Right rear speed sensor (ABS)
7 Not used
8 E/A DIAG_K Diagnosis TXD signal Data link connector
9 E A_LAT Transverse acceleration sensor
signal
Transverse acceleration sensor
10 M GND_LAT Ground Transverse acceleration sensor
11 A P_DRIV1 Voltage supply Pressure sensor
12 E 15A21 Terminal 15 Fuse 21
13 Not used
14 A VLP+ Activate precharge pump Precharge pump
15 E 30A52 Terminal 30 Fuse 52
16 E/A CAN_L CAN-bus Low Splice, CAN-bus Low
17 E/A CAN_H CAN-bus High Splice, CAN-bus High
18 Not used
19 A WLAS Warning lamp Instrument cluster
20 A SENS_DRI Pressure transmitter signal Pressure transmitter
21 A SENSP_LA Voltage supply Transverse acceleration sensor
22 A SENSP_YA Voltage supply RPM rate sensor
23 E SENS_DRI Pressure sensor signal Pressure sensor
24 M GND_DRIV Ground Pressure transmitter
25 M GND_YAW Ground RPM rate sensor
26 M GND_DRIV Ground Pressure sensor
27 E TCS DSC-ON-signal DSC switch
28 E PBRS Handbrake signal Handbrake switch
29 M GND Ground Ground point
