3452.1Ćb
2001
Pin Assignments (Z3 Versions Early Prod. and M Versions)
01/01
Z3
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionSignalType
30 E FR1 Speed signal Right front speed sensor (ABS)
31 M FR0 Ground Right front speed sensor (ABS)
32 A DFAHR Wheel speed signal, right rear Engine control module (DME)
33 E RL1 Speed signal Left rear speed sensor (ABS)
34 M RL0 Ground Left rear speed sensor (ABS)
35 Not used
36 A P_DRIV2 Voltage supply Pressure transmitter
37 Not used
38 E YAW_SIG RPM rate signal RPM rate sensor
39 Not used
40 E BLS Brake signal Brake light switch
41 E BRFN Brake fluid level signal Brake fluid level switch
42 E 30A53 Terminal 30 Fuse 53
43 E 30A51 Terminal 30 Fuse 51
