BMW Z3(E36/7) - X60005

BMW
BMW
BMWBMW
1210.26Ćf
2001
Pin Assignments (Z3 Versions)
01/01
Z3
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionSignalType
37 E/A CAN– CAN bus low Instrument cluster, ABS/ASC/DSC
control module, steering angle
sensor
38 Not used
39 Not used
40 Not used
X60005
Pin Type Signal Description/Function Connection
1 A P_ZSZ3 Ignition coil signal Cyl. 3 ignition coil
2 A P_ZSZ2 Ignition coil signal Cyl. 2 ignition coil
3 A P_ZSZ1 Ignition coil signal Cyl. 1 ignition coil
4 Not used
5 M 31L Ground Ground point
6 M A_ZSR Ground Ground point
7 A P_ZSZ6 Ignition coil signal Cyl. 6 ignition coil
8 A P_ZSZ5 Ignition coil signal Cyl. 5 ignition coil
9 A P_ZSZ4 Ignition coil signal Cyl. 4 ignition coil
