Pin Assignments (Z3 Versions)
01/01
Z3
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionSignalType
10 A EKP Activate relay Fuel pump relay
11 Not used
12 M M_FWG2 Ground Pedal position sensor
13 E A_FWG2 Signal, pedal position 2 Pedal position sensor
14 A U_FWG2 Voltage supply Pedal position sensor
15 Not used
16 Not used
17 A TD Crankshaft RPM speed signal (TD) Electronic immobilizer control
module (EWS III)/Thermal oil level
sensor (TOENS) control module
18 Not used
19 Not used
20 A S_DMTL Voltage supply Leakage diagnosis pump
21 Not used
22 E DFAHR Speed signal right rear ABS/ASC/DSC control module
23 E KUPP Clutch signal Clutch switch
24 E KL 54 ON Brake signal Brake light switch
25 Not used
26 E 15A26 Terminal 15 Fuse 26
27 E MFL Cruise control signal Cruise control interface
28 E S_BLTS Brake signal Brake light switch
29 A S_KOREL Activate relay Compressor control relay
30 A S_UVTL Activate changeover valve Leakage diagnosis pump
31 Not used
32 E/A TXDII TXD diagnosis data link Data link connector
33 E S_DWA Drive-away protection signal (code) Electronic immobilizer control
module (EWS III)
34 Not used
35 M 31 Ground Cruise control interface
36 E/A CAN+ CAN bus high Instrument cluster, ABS/ASC/DSC
control module, steering angle
sensor
