Pin Assignments
01/01
Z3
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionSignalType
19 M M_TOELG Oil temperature signal – Transmission valve unit
20 A S_MV1 Solenoid valve 1 control Transmission valve unit
21 Not used
22 Not used
23 A F_NTU+ Speed sensor turbine + Transmission valve unit
24 M F_NTU– Speed sensor turbine – Transmission valve unit
25 M W_NTU Ground for shield Shield for speed sensor turbine
26 Not used
27 Not used
28 Not used
29 Not used
30 Not used
31 Not used
32 E/A D_TXD2 TXD diagnostic data link Engine control module
33 Not used
34 Not used
35 Not used
36 E/A D_CAN-H CAN-bus High Engine control module
37 E/A D_CAN-L CAN-bus Low Engine control module
38 M W_NAB Ground for shield Shield for speed sensor
39 M F_NAB– Speed sensor shaft – Transmission valve unit
40 A F_NAB+ Speed sensor shaft + Transmission valve unit
