BMW Z3(E36/7) - Page 133

01/01
2460.14Ć
2001
01
A7000
TRANSMISSION
CONTROL MODULE
(EGS)
9
20
7
.5 OR/SW
10
3
.5 GN/RT
9
2
.5 GE
6
1
.5 SW/GE
8
6
.5 RT
19
.5 WS/RT
3
39
.35 BR
X70004
8
10
1
.35 WS .75 GN
NS
31 31 31 31 31 31 3131
38
Y8505y
TRANSMISSION
VALVE UNIT
1) SOLENOID VALVE 1
2) SOLENOID VALVE 2
3) SOLENOID VALVE 3
6) HYDRAULIC
PRESSURE
REGULATOR
7) TORQUE
CONVERTER
CLUTCH SOLENOID
VALVE
8) OIL TEMPERATURE
SENSOR
9) SPEED SENSOR
10) SPEED SENSOR
TURBINE
.5 SW/RT
17
14 9 5 20 X8505
136
24
.35 GR
31 31
25
15
18
.35 BL
10
NS
X85058
.75 VI
W9047
SHIELD
W9047
SHIELD
