BMW Z3(E36/7) - Page 139

BM
BMW
BMWBMW
Z3
3234.0Ćb
2001
Pin Assignments
01/01
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionType
30 Not used
31 Not used
32 Not used
33 A Air bag II (+) Passenger’s air bag gas generator
34 A Crash signal Body electronics control module (ZKE IV)
35 Not used
36 Not used
37 Not used
38 Not used
39 Not used
40 A Air bag II (–) Passenger’s air bag gas generator
41 Not used
42 Not used
43 Not used
44 Not used
45 Not used
46 Not used
47 Not used
48 Not used
49 A Battery safety terminal (+) Battery safety terminal
50 A Battery safety terminal (–) Battery safety terminal
