Pin Assignments (Z3 Versions Late Production)
01/01
Z3
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionSignalType
29 Not used
30 Not used
31 Not used
32 E 30A51 Terminal 30 Fuse 51
33 E FR1 Speed signal Right front speed sensor (ABS)
34 M FR0 Sensor ground Right front speed sensor (ABS)
35 Not used
36 M RL0 Sensor ground Left rear speed sensor (ABS)
37 E RL1 Speed signal Left rear speed sensor (ABS)
38 E BLS Brake signal Brake light switch
39 E TCS DSC-ON-signal DSC switch
40 E YAW_SIG RPM rate signal RPM rate sensor
41 Not used
42 E RR1 Speed signal Right rear speed sensor (ABS)
43 M RR0 Sensor ground Right rear speed sensor (ABS)
44 A WLAS Warning lamp Instrument cluster
45 M FL0 Sensor ground Front left speed sensor (ABS)
46 E FL1 Speed signal Front left speed sensor (ABS)
47 M GND Ground Ground point
