Pin Assignments (Z3 Versions)
01/01
Z3
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionSignalType
5 E P_NWGE1 Signal camshaft position Camshaft position sensor 1 (inlet)
6 Not used
7 A U_DKG Voltage supply Electrical gas actuator
8 E P_KWG Signal crankshaft position Crankshaft position sensor
9 Not used
10 E A_DKG2 Throttle position signal 2 Electrical gas actuator
11 Not used
12 Not used
13 Not used
14 Not used
15 M M_NWGA1 Ground Camshaft position sensor 2 (outlet)
16 Not used
17 M M_HFM Ground Hot film air massmeter
18 M M_NWGE1 Ground Crankshaft position sensor 1 (inlet)
19 E A_DKG1 Throttle position signal 1 Electrical gas actuator
20 M M_DKG Ground Electrical gas actuator
21 M M_KWG Ground Crankshaft position sensor
22 E A_TANS Temperature signal Intake air temperature sensor
23 M M_TANS Ground Intake air temperature sensor
24 E A_TMOT Temperature signal Engine coolant temperature sensor
25 M M_TMOT Ground Engine coolant temperature sensor
26 Not used
27 E A_TOEL Temperature signal Oil temperature sensor
28 M M_TOEL Ground Oil temperature sensor
29 E A_KS1A Cyl. 1-3 knock sensor Double knock sensor
30 E A_KS1B Cyl. 1-3 knock sensor Double knock sensor
31 E A_KS2A Cyl. 4-6 knock sensor Double knock sensor
32 E A_KS2B Cyl. 4-6 knock sensor Double knock sensor
33 A P_EVZ1 Activate valve Cyl. 1 fuel injection valve
34 A P_EVZ2 Activate valve Cyl. 2 fuel injection valve
35 A P_EVZ3 Activate valve Cyl. 3 fuel injection valve
36 A P_EVZ4 Activate valve Cyl. 4 fuel injection valve
