Pin Assignments (4-Cylinder)
04/99
BM
BMW
BMWBMW
Z3
E = Input, A = Output, M = Ground
X8500
Pin Type Description/Function Connection
265 Not used
266 A Shift-lock solenoid control Shift-lock
267 Not used
268 A Solenoid valve 3 control (–) Transmission valve unit
269 A Hydraulic pressure regulator control (–) Transmission valve unit
270 M Ground Ground point
271 Not used
272 E Gear range signal L2 Automatic transmission range switch
273 E Gear range signal L4 Automatic transmission range switch
274 E Brake pedal position Brake light switch
275 Not used
276 E Sport mode signal Not used
277 E Manual mode signal Program switch
278 E Output speed (–) Transmission valve unit
279 M Ground for shield Shield for speed sensor
280 Not used
281 A S-program indication Not used
282 E Kick-down signal Kick-down switch
283 Not used
284 E Automatic mode signal Program switch
285 E Oil temperature signal (–) Transmission valve unit
286 E Oil temperature signal (+) Transmission valve unit
287 Not used
288 Not used
289 A Fault indicator signal Instrument cluster
290 E Battery voltage B+ jump start junction point
291 A M-program indication Program switch
292 M Ground Ground point
293 Not used
294 A Solenoid valve 1 control (–) Transmission valve unit
