2460.2bĆb
1998
Pin Assignments (4-Cylinder)
04/99
BM
BMW
BMWBMW
Z3
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionType
295 Not used
296 A Torque converter clutch solenoid valve
control (–)
Transmission valve unit
297 A Solenoid valve 2 control (–) Transmission valve unit
298 M Ground Ground point
299 Not used
300 E Gear range signal L1 Automatic transmission range switch
301 E Gear range signal L3 Automatic transmission range switch
302 Not used
303 Not used
304 E RPM speed signal TD Engine control module
305 Not used
306 E Output speed (+) Transmission valve unit
307 Not used
308 Not used
309 A A-program indication Program switch
310 E A/C compressor-ON-signal Engine control module
311 Not used
312 E Brake switch test signal Brake light switch
313 Not used
314 Not used
315 Not used
316 A Voltage supply Shift-lock/Transmission valve unit
317 E Voltage pressure regulator Transmission valve unit
318 E Voltage supply, terminal 87 Engine control module relay
319 E Voltage supply, terminal 87 Engine control module relay
320 Not used
321 Not used
322 Not used
323 Not used
324 Not used
325 Not used
