04/99
2460.2Ć
1998
01
A8500
TRANSMISSION
CONTROL MODULE
(EGS)
9
32
7
.5 BL
4
3
.5 VI
33
2
.5 GN
30
1
.5 OR
5
6
.5 GR
21
.5 SW
2
14
.5 SW
X8500
8
14
1
.5 RT
.5 GE .75 RT
NS
31 31 31 31 31 31 31
W8505
SHIELD UP TO
10mm BEFORE
ELECTRONIC
TRANSMISSION
OUTPUT SHAFT
SPEED SENSOR
(EGS)
31
15
X8516
X8516
Y8521
TRANSMISSION
VALVE UNIT
1) SOLENOID
VALVE 1
2) SOLENOID
VALVE 2
3) SOLENOID
VALVE 3
6) HYDRAULIC
PRESSURE
REGULATOR
7) TORQUE
CONVERTER
CLUTCH
SOLENOID
VALVE
8) OIL
TEMPERATURE
SENSOR
9) SPEED
SENSOR
DR
.5 TR
.75 BR
X8073
2 X85054
1 12 9 11 X8505
616
