Pin Assignments
04/99
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionType
81 Not used
82 Not used
83 Not used
84 E Signal, left rear speed sensor Left rear speed sensor
85 E Signal, right rear speed sensor Right rear speed sensor
86 A Ground, right front speed sensor Right front speed sensor
87 E Signal, left front speed sensor Left front speed sensor
88 Not used
89 A Activate rear outlet valve ABS hydraulic unit
90 A Activate rear front inlet valve ABS hydraulic unit
91 M Ground Ground point
92 A Activate ABS lamp control Instrument cluster
