BMW Z3 E37 1998 - Page 161

paragon.myvnc.com
04/99
3614.0Ć
1998
00
3614.0 TIRE INFLATION SYSTEM
BM
BMW
BMWBMW
Z3
E28a
CIGAR LIGHTER
CONNECTION
8 6 X6394
X63942
K6394
COMPRESSOR
RELAY
2.5 SW
X12552
M805
ELECTRICAL COM-
PRESSOR
2.5 SW
4
1 RT/WS
4
.5 WS
X12551
2.5 BL
1
1 BR/RT
3
.5 WS
X3206
10
1
X3940
E28a
CIGAR LIGHTER
CONNECTION
–
+
1 X3040
2.5 RT1 RT
2.5 RT
X693
S232
COMPRESSOR
MAIN SWITCH
0) OFF
1) ON
X3158
1 BR
2.5 BR
2.5 BR
X3040
2
M ROADSTER
