SLIP CONTROL (ABS/ASC)
04/99
3450.1Ć
1998
13
10 36 13 12 15 14
11 38 X1175
.5 GE
.5 WS
.5 GE .5 GN
1 2 2 1 X142 2 1 2 1 X143
B2
LEFT FRONT
SPEED SENSOR –
ABS
B4
LEFT REAR SPEED
SENSOR – ABS
B1
RIGHT FRONT
SPEED SENSOR –
ABS
B3
RIGHT REAR
SPEED SENSOR –
ABS
LEFT FRONT
PULSE WHEEL
A52
SLIP CONTROL
MODULE
(ABS/ASC)
LEFT REAR PULSE
WHEEL
RIGHT FRONT
PULSE WHEEL
RIGHT REAR
PULSE WHEEL
31 31 31 31
X114 X113
BM
BMW
BMWBMW
Z3
X18170
3 3
GROUND
DISTRIBUTION
0670.4
GROUND
DISTRIBUTION
0670.4
X18170
31 31
M ROADSTER
