5430.2 ELECTRO–HYDRAULIC CONVERTIBLE TOP
X100152
FUSE DETAILS
0670.3
X1001832
FUSE DETAILS
0670.3
S30
BRAKE LIGHT
SWITCH
1) BRAKE PEDAL
RELEASED
2) BRAKE PEDAL
DEPRESSED
1 X78
2.5 RT/GE
F1
30A
F46
15A
1.5 BL/RT
12
X78
2
X181
4 X13146
4 X1836365
2 X18363
8
.5 BL/RT
X1215
8 X18364
P90
FRONT POWER
DISTRIBUTION BOX
BRAKE LIGHTS
6325.0
.5 BL/RT
.5 BL/RT
K18364
CONVERTIBLE TOP
RELAY II (OPEN)
2
M101
CONVERTIBLE TOP
MOTOR
X18364
46
K18363
CONVERTIBLE TOP
RELAY I (CLOSE)
5
X1116 X1116
GROUND
DISTRIBUTION
0670.4
GROUND
DISTRIBUTION
0670.4
.5 BR/GE
2 X231461
2.5 RT/GE
2.5 SW/GE
.5 BL/RT
2.5 SW/BL .5 BR/RT
