Pin Assignments
04/99
BM
BMW
BMWBMW
Z3
E = Input, A = Output, M = Ground
A = X10182 18 Pins, black
B = X13252 15 Pins, black
C = X13253 26 Pins, yellow
D = X13254 26 Pins, green
X10182
Pin Type Description/Function Connection
1 E Crash signal Crash control module
2 E Light signal Light switch
3 Not used
4 E Power supply Front power distribution box, fuse 43
5 M Ground Ground point
6 Not used
7 Not used
8 Not used
9 A Diagnosis RxD signal Data link connector
10 Not used
11 E/A Diagnosis TxD signal Data link connector
12 E Start signal Starter
13 Not used
14 Not used
15 A Drive-away protection Electronic immobilizer control module
(EWS II)
16 Not used
17 Not used
18 E Power supply Front power distribution box
