BMW Z3 E37 1998 - Page 197

paragon.myvnc.com
BMW
BMW
BMW
6211.0Ćc
1998
Pin Assignments
04/99
BM
BMW
BMWBMW
Z3
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionType
24 Not used
25 Not used
26 Not used
X271
Pin Type Description/Function Connection
1 A Fuel level sensor Fuel tank sensors
2 Not used
3 A Ground supply for fuel tank sensor and
vehicle speed sensor
Fuel tank sensor and vehicle speed
sensor
4 E Position signal TW Vehicle speed sensor
5 Not used
6 Not used
7 Not used
8 Not used
9 Not used
10 Not used
11 Not used
12 Not used
