FOCUS 1.4 Settings
P051 Modbus baud rate
The value shown here indicates the data signalling rate [Bits/s] of the RS485-
interface of the main board for the communication with an external Bus system
– e.g. a master control.
P052 Modbus frame
The protocol frame of the RS485 interface is determined here. 8 data bits are
transmitted and the parity can be selected (O = Odd ; E = Even ; N = None),
as well as the number of stop bits (1 or 2).
P053 Modbus address (module)
The set value 0...248 indicates the Bus address of the RS485 interface on the
basic module for the communication with additional compressors.
0 stands for master, additionally connected compressors have to be specified
with the values 2...4.
P054 Modbus baud rate (module)
The value shown here indicates the data signalling rate [Bits/s] of the RS485-
interface of the module for the communication with additional compressors.
P055 Modbus frame (module)
The protocol frame is determined here. 8 data bits are transmitted and the par-
ity can be selected (O = Odd, E = Even or N = None), as well as the number
of stop bits (1 or 2).
P060 Contact type for compressed air treatment
By this parameter it can be declared whether the signalling contact for the
compressed air purification is a break contact or a make contact.
0: Break contact
1: Make contact
Note!
For all units within the Bus system this value must be the same.
Note!
For all units within the Bus system this value must be the same.
Note!
The address must be unique in the Bus system.
Note!
For all units within the Bus system this value must be the same.
Note!
For all units within the Bus system this value must be the same.
