Boge FOCUS - Data of external connections; Basic module

BOGE FOCUS compressor control for piston compressors Page 29
FOCUS 1.8 Data of external connections
1.8 Data of external connections
Basic module
Terminals Type of
terminal
Function Description Rating
1/2 Tension
spring
terminal
Relay output Ready for operation:
Make contact
2A 30V DC/250 with ohmic load V AC;
0.6A 250V AC 50/60 Hz with inductive load
(Power factor = 0.4)
3/4/5 Tension
spring
terminal
Relay output Fault-free:
Grouping terminal 3,
Break contact terminal 4
and Make contact termi-
nal 5
2A 30V DC/250 with ohmic load V AC;
0.6A 250V AC 50/60 Hz with inductive load
(Power factor = 0.4)
6/7 Tension
spring
terminal
Relay output Operation:
Make contact
2A 30V DC/250 with ohmic load V AC;
0.6A 250V AC 50/60 Hz with inductive load
(Power factor = 0.4)
8/9 Tension
spring
terminal
Relay output Load operation:
Make contact
2A 30V DC/250 with ohmic load V AC;
0.6A 250V AC 50/60 Hz with inductive load
(Power factor = 0.4)
10/11 Tension
spring
terminal
Relay output Serviving:
Make contact
2A 30V DC/250 with ohmic load V AC;
0.6A 250V AC 50/60 Hz with inductive load
(Power factor = 0.4)
12/13 Tension
spring
terminal
Relay output Pre-selection remote:
Make contact
2A 30V DC/250 with ohmic load V AC;
0.6A 250V AC 50/60 Hz with inductive load
(Power factor = 0.4)
14/15 Tension
spring
terminal
Relay output Timer:
Make contact
2A 30V DC/250 with ohmic load V AC;
0.6A 250V AC 50/60 Hz with inductive load
(Power factor = 0.4)
34 Tension
spring
terminal
Digital input Monitoring compressed
air treatment
Terminal 34 (against
terminal 31 (+24V))
24...31V DC, 10mA,
Input resistance 3 kΩ
40 Tension
spring
terminal
Digital input Output release
Terminal 40 (against
terminal 31 (+24V))
24...31V DC, 10mA,
Input resistance 3 kΩ
41 Tension
spring
terminal
Digital input Remote Start/stop switch
Terminal 41 (against
terminal 31 (+24 V))
24...31V DC, 10mA,
Input resistance 3 kΩ
42 Tension
spring
terminal
Digital input Switchover pressure
range
Terminal 42 (against
terminal 31 (+24V))
24...31V DC, 10mA,
Input resistance 3 kΩ
