-- 11 --
④ MARKER
For Marker selecting button, ‘Marker’ is displayed on screen.
In case input signals are DVI ,RGB, PC-RGB and YUV, Marker is not displayed.
⑤ FUNCTION 1(F1)
Function buttons are selected from SYSTEM menu. They are operated by F1, F2 Buttons.
⑥ FUNCTION 2(F2)
1) In case it is not OSD Menu working, it works to be the selected function on the SYSTEM
Menu.
2) When OSD Menu setting, it works as a DOWN (▼) Button.
⑦ BLUE / GRAY
1) Each time, user can press the button, the mode changes as follows.
(BLUE Only -> GRAY -> Normal)
2) When on OSD Menu, it works as a UP(▲) Button.
* BLUE Only : Only Blue signal is displayed on screen.
* GRAY : with color off, only Luminance is displayed.
GRAY(Mono) function operates in SDI1,2, CVBS1,2,3 and YC mode.
⑧ MENU
When pressing button, OSD menu is displayed.
⑨ ENTER / ADJUST
1) OSD Menu setting is by Enter key. Save setting functions, after that, move to next step.
2) Except for Menu operation, each time you press the ADJUST button, it changes sequentially.
” Brightness” ->”Contrast”-> “Phase(Hue)”-> “Saturation”-> “Sharpness” -> Speaker Volume
and then, control Bar is displayed on screen bottom and the set Button of UP(▲) , Down (▼) button
can change and can be saved to be function of ENTER/ADJUST button.
⑩ STANDBY
It can be used to be power on/ off button.
⑪ IR Remote receiver (BLM-320,420,470,550)
This is for BLM-320 to BLM-550 products.
!
Brightness
Contrast Possible to control 6 types.
Volume
Hue (Phase)
Saturation
Sharpness
Speaker Volume, Hue,
Saturation and Sharpness could
not be supported by option.
