-- 14 --
3-3 Tally & Audio
1) Tally
Tally colors are 2 types. (Red, Green).
It can be selected by external contact terminal.
Tally Lamp
① Analog Audio L/R Input Terminal (RCA Phone)
The external audio signal is output through the speaker by Menu setting.
② Analog Audio L/R Output Terminal (RCA Phone)
Terminal for output of De-embedded Analog Audio signal from SDI.
16ch Audio Signal output is available with menu setting.
2) Audio Input (BMA-20A)
The function of Audio In/Out is option.
( Not for 8.4”)
