-- 13 --
BLM- Series
①② SDI 1 , SDI 2 Input Terminal (BNC)
These function are for HD/SD-SDI input terminal and provide SMPTE standard and
16ch audio signal .
③ SDI SELECTOUT Terminal (BNC)
Output terminal for the HD/SD-SDI signals.
It do not output when the monitor is off. (Active Select Output)
④,⑤,⑥ : CVBS (Composite) 1,2,3 /Y, Pb, Pr / R, G, B / Y,C Input Terminal (BNC)
These are for Analog input terminal. Possible to use 3 types of input signal.
1) Composite 1,2,3.
2) Component Y,U,V(Y,Pb,Pr) and R,G,B.
3) S-Video Y,C signal.
④’,⑤’,⑥’ : LOOPOUT Terminal (BNC)
Loop output terminal of Analog input signal.
In case user do not connect Loop output terminal, make Analog Loop NO in the
OSD menu.
⑦ DVI-I / PC-RGB Input Terminal (DVI-I Jack)
1) Terminal for input DVI digital signal.
2) When DVI to VGA Gender using, it is possible to input PC-RGB(VGA) signal.
⑧ REMOTE Terminal, RJ-45 Jack-Through (RJ-45) Terminal
Terminal for controlling the monitor by an external control. (Make/Trig type)
⑧’ : Audio Input/Output Terminal
In/Output terminal for the external Audio and Embedded Audio signal.
⑨ UPDATE Terminal (RJ-11 Jack)
Terminal for changing or upgrade the monitor of working program.
⑩ DC INPUT Terminal (BLM-084,BLM-170)
Use for 12V DC power (12V~17V).
⑪ AC INPUT Terminal
Supply AC power
Do not use AC and DC power together. It may be cause of fire or product defective.
!
!
Use only the power cord designated to ensure safety and EMC
regulation of each countries.
