BONFIGLIOLI 300 Series User Manual

43 / 52
N.B.: MAKE SURE THE ROD IS POSITIONED FLAT
AGAINST THE EDGE OF THE THREADED HOLE
ANNEX 2 - LUBRICANT CHARGE QUANTITY
3_L Series
N.B. Oil quantities are indicative. Check actual level after  lling through the appropriate plug.
A T O
300
L1 0.6 1.0 0.9
L2 0.9 1.3 1.2
L3 1.2 1.6 1.5
L4 1.5 1.9 1.8
301
L1 0.8 1.2 1.1
L2 1.1 1.5 1.4
L3 1.4 1.8 1.7
L4 1.7 2.1 2.0
303
L1 1.3 2.3 2.0
L2 1.6 2.6 2.3
L3 1.9 2.9 2.6
L4 2.2 3.2 2.9
304
L1 1.4 2.4 2.2
L2 1.9 2.9 2.7
L3 2.2 3.2 3.0
L4 2.5 3.5 3.3
305
L1 1.6 2.6 2.4
L2 2.1 3.1 2.9
L3 2.4 3.4 3.2
L4 2.7 3.7 3.5
306
L1 2.5 3.5 3.2
L2 3.3 4.3 4.0
L3 3.6 4.6 4.3
L4 3.9 4.9 4.6
307
L1 3.5 5.0 4.5
L2 4.5 6.0 5.5
L3 5.0 6.5 6.0
L4 5.3 6.8 6.3
309
L1 4.0 5.5 5.0
L2 5.0 6.5 6.0
L3 5.5 7.0 6.5
L4 5.8 7.3 6.8
A T O
310
310M
L1 5.0 6.5 6.0
L2 6.3 7.8 7.3
L3 7.1 8.6 8.1
L4 7.4 8.9 8.4
311
311M
L1 7.0 12 10
L2 9.0 14 12
L3 10 15 13
L4 11 16 14
313
313M
L1 9.0 14 12
L2 12 17 15
L3 13 18 16
L4 13 18 16
314
314M
L2 17 25 21
L3 19 27 23
L4 20 28 24
315
315M
L2 19 27 23
L3 21 29 25
L4 22 30 26
316
316M
L2 22 30 26
L3 24 32 28
L4 25 33 29
317
317M
L2 26 41 36
L3 29 44 39
L4 30 45 40
318
318M
L3 40 55 50
L4 43 58 53
319
L3 50 70 60
L4 53 73 63
321
L3 56 76 66
L4 60 80 70
323
L3
L4
325
L3
L4
Mounting position Mounting position
Contact Bon glioli Riduttori
Technical Service
