5.1.3 Shaft mounting
Mount the torque arm with bolts of class and torque as indicated in the table below:
300...321
310M...318M
300 301 303 304 305 306 307 309
310
310M
311
311M
313
313M
314
314M
315
315M
316
316M
317
317M
318
318M
319 321
M16 M16 M16 M16 M16 M20 M24 M24 M24 M30 M30 M30 M30 M36 M30 M36 M48 M48
4 4 4 4 4 4 4 4 4 4 4 8 8 8 8 8 4 8
8.8 8.8 8.8 8.8 8.8 8.8 8.8 8.8 8.8 8.8 8.8 8.8 8.8 8.8 8.8 8.8 8.8 8.8
200 200 200 200 200 400 700 700 700 1400 1400 1400 1400 2500 1400 2500 6000 6000
Bolt
Quantity
Class
Tightening
torque [Nm]
5.1.2 Foot mounting
Foot-mounted motor execution
Gear units of this type must be mounted on a suitably rigid base, machined at with a planarity
error margin of no more than 0.2 mm / 100 mm.
See diagram below:
Foot-mounted gear unit mounting bolts
300...325
310M...318M
300 301 303 304 305 306 307 309
310
310M
311
311M
313
313M
314
314M
315
315M
316
316M
317
317M
318
318M
319 321 323 325
M10 M10 M12 M12 M12 M14 M16 M16 M16 M16 M16 M20 M20 M20 M30 M27 M30 M30 M42 M42
8 8 10 10 10 12 10 12 15 24 30 20 20 30 24 32 30 36 36 36
12.9 12.9 12.9 12.9 12.9 12.9 12.9 12.9 12.9 12.9 12.9 12.9 12.9 12.9 12.9 12.9 12.9 12.9 12.9 12.9
85 85 145 145 145 230 350 350 350 350 350 690 690 690 2350 1750 1750 1750 6750 6750
Bolt
Quantity
Class
Tightening
torque [Nm]
