50 / 52
O-Q
300 - 307
300 - 307
T-V
300 - 307
A-E
ALL GEARBOXES
(planetary stages)
1 Filling/breather oil plug
2 Oil level plug
3 Oil draining plug
(helical bevel reduction module)
1A Filling/breather oil plug
2A Oil level plug
3A Oil draining plug
3/A Series
