freno c.c. / d.c. brake
G.S.-bremse / frein c.c.
freno c.a. / a.c. brake
W.S.-bremse / frein c.a.
FD FA BA
Pn
kW
n
min
-1
Mn
Nm
h
%
cos j
In
[400V]
A
Is
In
Ms
Mn
Ma
Mn
Jm
x10
-4
kgm
2
IM B5
Mod.
Mb
Nm
Z
o
1/h
Jm
x10
-4
kgm
2
IM B5
Mod.
Mb
Nm
Z
o
1/h
Jm
x10
-4
kgm
2
IM B5
Mod.
Mb
max
Nm
Z
o
1/h
Jm
x10
-4
kgm
2
IM B5
0.37
BN 80A 4
1400 2.5 63 0.82 1.03 3.3 1.4 1.4 15 8.2
FD 04
10 2300 3500 16.6 12.1
FA 04
10 3500 16.6 12.0
BA 80
18 3200 18 13.5
0.18
8
690 2.5 44 0.60 0.98 2.2 1.5 1.6 4500 7000 7000 6500
0.55
BN 80B 4
1390 3.8 65 0.86 1.42 3.8 1.7 1.6 20 9.9
FD 04
10 2200 2900 22 13.8
FA 04
10 2900 22 13.7
BA 80
18 2500 23 15.2
0.30
8
670 4.3 49 0.65 1.36 2.3 1.7 1.8 4200 6500 6500 5600
0.65
BN 90S 4
1390 4.5 73 0.85 1.51 4.0 1.9 1.9 28 13.6
FD 14
15 2300 2800 30 17.8
FA 14
15 2800 30 17.7
BA 90
35 2400 35 21
0.35
8
690 4.8 49 0.57 1.81 2.5 2.1 2.2 3500 6000 6000 5100
0.9
BN 90L 4
1370 6.3 73 0.87 2.05 3.8 1.8 1.8 30 15.1
FD 05
26 1700 2100 34 21
FA 05
26 2100 34 22
BA 90
35 1900 37 22
0.5
8
670 7.1 57 0.62 2.04 2.4 2.1 2 2500 4200 4200 3800
1.3
BN 100LA 4
1420 8.7 72 0.83 3.14 4.3 1.7 1.8 82 22
FD 15
40 1300 1700 86 28
FA 15
40 1700 86 29
BA 100
50 1500 94 32
0.7
8
700 9.6 58 0.64 2.72 2.8 1.8 1.8 2000 3400 3400 3100
1.8
BN 100LB 4
1420 12.1 69 0.87 4.3 4.2 1.6 1.7 95 25
FD 15
40 1200 1700 99 31
FA 15
40 1700 99 32
BA 100
50 1500 107 34
0.9
8
700 12.3 62 0.63 3.3 3.2 1.7 1.8 1600 2600 2600 2400
2.2
BN 112M 4
1440 14.6 77 0.85 4.9 5.3 1.8 1.8 168 32
FD 06S
60 — 1200 177 42
FA 06S
60 1200 177 43
BA 110
75 1100 184 45
1.2
8
710 16.1 70 0.63 3.9 3.3 1.9 1.8 — 2000 2000 1900
3.6
BN 132S 4
1440 24 80 0.82 7.9 6.5 2.1 1.9 295 45
FD 56
75 — 1000 305 58
FA 06
75 1000 305 59
BA 140
150 900 345 77
1.8
8
720 24 72 0.55 6.6 4.6 1.9 2 — 1400 1400 1200
4.6
BN 132M 4
1450 30 81 0.83 9.9 6.5 2.2 1.9 383 56
FD 06
100 — 1000 393 69
FA 07
100 1000 406 74
BA 140
150 900 433 88
2.3
8
720 31 73 0.54 8.4 4.4 2.3 2 — 1300 1300 1200
1500/750 min
-1
-S1
4/8 P
50 Hz
