BONFIGLIOLI AS 30 User Manual

26
22 - GETRIEBEMOTORENAUS-
WAHLTABELLEN
22 - GEARMOTOR SELECTION
CHARTS
22 - DONNEES TECHNIQUES
MOTOREDUCTEURS
22 - DATI TECNICI
MOTORIDUTTORI
0.09 kW
4.7 169 1.2 192.1 3200 AS 25 D_063 B5 BN 63A 6 74
5.8 139 1.4 157.9 3200 AS 25 D_063 B5 BN 63A 6 74
6.3 127 1.6 144.4 3200 AS 25 D_063 B5 BN 63A 6 74
7.4 108 1.9 122.5 3200 AS 25 D_063 B5 BN 63A 6 74
7.6 105 0.9 120.1 2800 AS 20 D_063 B5 BN 63A 6 72
8.3 96 2.1 109.1 3200 AS 25 D_063 B5 BN 63A 6 74
8.4 95 1.1 108.1 2800 AS 20 D_063 B5 BN 63A 6 72
9.3 86 1.2 97.7 2800 AS 20 D_063 B5 BN 63A 6 72
10.1 79 2.5 89.7 3200 AS 25 D_063 B5 BN 63A 6 74
11.1 72 2.8 82 3200 AS 25 D_063 B5 BN 63A 6 74
11.2 72 1.4 81.4 2800 AS 20 D_063 B5 BN 63A 6 72
13.1 61 3.3 69.6 3200 AS 25 D_063 B5 BN 63A 6 74
13.1 61 1.6 69.2 2800 AS 20 D_063 B5 BN 63A 6 72
14.2 56 1.8 64.3 2800 AS 20 D_063 B5 BN 63A 6 72
15.7 51 2.0 58.1 2800 AS 20 D_063 B5 BN 63A 6 72
18.4 44 2.0 49.52 2800 AS 20_ 063 B5 BN 63A 6 72
20.3 40 2.2 44.77 2800 AS 20_ 063 B5 BN 63A 6 72
20.3 40 1.1 44.73 1170 AS 16_ 063 B5 BN 63A 6 70
22.6 36 1.2 40.32 1150 AS 16_ 063 B5 BN 63A 6 70
24.4 33 2.7 37.31 2800 AS 20_ 063 B5 BN 63A 6 72
25.0 33 1.4 36.36 1140 AS 16_ 063 B5 BN 63A 6 70
27.8 29 1.5 32.78 1110 AS 16_ 063 B5 BN 63A 6 70
28.7 28 3.2 31.71 2790 AS 20_ 063 B5 BN 63A 6 72
32 25 3.6 28.13 2710 AS 20_ 063 B5 BN 63A 6 72
34 24 1.8 27.14 1070 AS 16_ 063 B5 BN 63A 6 70
36 23 3.9 25.43 2630 AS 20_ 063 B5 BN 63A 6 72
43 19 2.4 20.96 1020 AS 16_ 063 B5 BN 63A 6 70
48 17 2.7 18.89 1000 AS 16_ 063 B5 BN 63A 6 70
58 14 3.2 15.64 950 AS 16_ 063 B5 BN 63A 6 70
73 11 4.0 12.47 900 AS 16_ 063 B5 BN 63A 6 70
81 10 4.5 11.24 880 AS 16_ 063 B5 BN 63A 6 70
98 8 5.4 9.31 830 AS 16_ 063 B5 BN 63A 6 70
123 7 6.8 7.41 780 AS 16_ 063 B5 BN 63A 6 70
136 6 7.5 6.68 760 AS 16_ 063 B5 BN 63A 6 70
164 5 9.1 5.53 720 AS 16_ 063 B5 BN 63A 6 70
5.8 185 1.1 157.9 3200 AS 25 D_063 B5 BN 63B 6 74
6.3 169 1.2 144.4 3200 AS 25 D_063 B5 BN 63B 6 74
7.3 146 1.2 192.1 3200 AS 25 D_063 B5 BN 63A 4 74
7.4 144 1.4 122.5 3200 AS 25 D_063 B5 BN 63B 6 74
8.3 128 1.6 109.1 3200 AS 25 D_063 B5 BN 63B 6 74
8.9 120 1.5 157.9 3200 AS 25 D_063 B5 BN 63A 4 74
9.7 110 1.6 144.4 3200 AS 25 D_063 B5 BN 63A 4 74
10.1 105 1.9 89.7 3200 AS 25 D_063 B5 BN 63B 6 74
11.1 96 2.1 82 3200 AS 25 D_063 B5 BN 63B 6 74
11.2 95 1.0 81.4 2800 AS 20 D_063 B5 BN 63B 6 72
11.4 93 1.9 122.5 3200 AS 25 D_063 B5 BN 63A 4 74
11.7 91 1.0 120.1 2800 AS 20 D_063 B5 BN 63A 4 72
12.8 83 2.2 109.1 3200 AS 25 D_063 B5 BN 63A 4 74
13.0 82 1.1 108.1 2800 AS 20 D_063 B5 BN 63A 4 72
13.1 82 2.5 69.6 3200 AS 25 D_063 B5 BN 63B 6 74
13.1 81 1.2 69.2 2800 AS 20 D_063 B5 BN 63B 6 72
14.2 75 1.3 64.3 2800 AS 20 D_063 B5 BN 63B 6 72
n
2
min
-1
M
2
Nm
SiRn
2
N
0.12 kW
