BONFIGLIOLI AS 30 User Manual

57
AS 30
350 Nm
AS 30_ 5.11 548 160 9.7 530 1100 274 230 6.9 550 1350
77
AS 30_ 6.22 450 180 8.9 710 1200 225 230 5.7 850 1500
AS 30_ 6.93 404 180 8.0 930 1300 202 230 5.1 1000 1600
AS 30_ 7.51 373 180 7.4 590 1300 186 230 4.7 700 1600
AS 30_ 7.78 360 180 7.1 1000 1400 180 230 4.6 1000 1750
AS 30_ 9.14 306 210 7.1 690 1300 153 260 4.4 920 1650
AS 30_ 10.18 275 210 6.4 910 1400 138 260 3.9 1000 1800
AS 30_ 11.43 245 210 5.7 1000 1550 122 260 3.5 1000 2000
AS 30_ 12.62 222 220 5.4 460 1500 111 260 3.2 770 2000
AS 30_ 15.37 182 240 4.8 710 1600 91 260 2.6 1000 2300
AS 30_ 17.11 164 240 4.3 930 1750 82 260 2.3 1000 2500
AS 30_ 19.21 146 240 3.9 1000 1900 73 260 2.1 1000 2600
AS 30_ 24.19 116 250 3.2 430 2000 58 320 2.0 490 2500
AS 30_ 29.45 95 300 3.1 460 2000 48 320 1.7 1000 2800
AS 30_ 32.8 85 320 3.0 560 2000 43 320 1.5 1000 3050
AS 30_ 36.82 76 320 2.7 810 2200 38 320 1.3 1000 3300
AS 30 D_ 41.2 68 320 2.5 660 2350 34 320 1.2 660 3500
AS 30 D_ 46.2 61 320 2.2 660 2550 30 320 1.1 660 3700
AS 30 D_ 54.0 52 320 1.9 660 2650 25.9 320 0.94 660 3900
AS 30 D_ 65.8 43 320 1.5 660 3050 21.3 320 0.77 660 4300
AS 30 D_ 73.6 38 320 1.4 660 3250 19.0 320 0.69 660 4600
AS 30 D_ 82.2 34 320 1.2 660 3500 17.0 320 0.62 660 4860
AS 30 D_ 99.3 28.2 320 1.0 660 3700 14.1 320 0.51 660 5200
AS 30 D_ 120.9 23.2 320 0.84 660 4150 11.6 320 0.42 660 5500
AS 30 D_ 134.7 20.8 320 0.75 660 4400 10.4 320 0.38 660 5500
AS 30 D_ 151.1 18.5 320 0.67 660 4700 9.3 320 0.33 660 5500
i
n
1
= 2800 min
-1
n
1
= 1400 min
-1
n
2
min
-1
M
n2
Nm
P
n1
kW
R
n1
N
R
n2
N
n
2
min
-1
M
n2
Nm
P
n1
kW
R
n1
N
R
n2
N
n
1
= 900 min
-1
n
1
= 500 min
-1
AS 30_ 5.11 176 320 6.2 400 1370 98 350 3.8 430 1590
77
AS 30_ 6.22 145 320 5.1 590 1230 80 350 3.1 900 1790
AS 30_ 6.93 130 320 4.6 740 1210 72 350 2.8 1000 2080
AS 30_ 7.51 120 320 4.2 530 1670 67 350 2.6 670 2080
AS 30_ 7.78 116 320 4.1 1000 1610 64 350 2.5 1000 2270
AS 30_ 9.14 98 320 3.5 870 1810 55 350 2.1 1000 2440
AS 30_ 10.18 88 320 3.1 1000 1980 49 350 1.9 1000 2650
AS 30_ 11.43 79 320 2.8 1000 2170 44 350 1.7 1000 2870
AS 30_ 12.62 71 320 2.5 680 2170 39.6 350 1.5 1000 2890
AS 30_ 15.37 59 320 2.1 1000 2520 32.5 350 1.3 1000 3310
AS 30_ 17.11 53 320 1.9 1000 2720 29.2 350 1.1 1000 3540
AS 30_ 19.21 47 320 1.7 1000 2930 26.0 350 1.0 1000 3800
AS 30_ 24.19 37.2 320 1.3 1000 3180 20.7 350 0.80 1000 4120
AS 30_ 29.45 30.6 320 1.1 1000 3600 17.0 350 0.65 1000 4620
AS 30_ 32.8 27.4 320 0.97 1000 3840 15.2 350 0.59 1000 4900
AS 30_ 36.82 24.4 320 0.86 1000 4090 13.6 350 0.52 1000 5210
AS 30 D_ 41.2 21.8 350 0.86 660 4100 12.1 350 0.48 660 5450
AS 30 D_ 46.2 19.5 350 0.77 660 4400 10.8 350 0.43 660 5500
AS 30 D_ 54.0 16.7 350 0.66 660 4600 9.3 350 0.37 660 5500
AS 30 D_ 65.8 13.7 350 0.54 660 5200 7.6 350 0.30 660 5500
AS 30 D_ 73.6 12.2 350 0.48 660 5450 6.8 350 0.27 660 5500
AS 30 D_ 82.2 10.9 350 0.43 660 5500 6.1 350 0.24 660 5500
AS 30 D_ 99.3 9.1 350 0.36 660 5500 5.0 350 0.20 660 5500
AS 30 D_ 120.9 7.4 350 0.29 660 5500 4.1 350 0.16 660 5500
AS 30 D_ 134.7 6.7 350 0.26 660 5500 3.7 350 0.15 660 5500
AS 30 D_ 151.1 6.0 350 0.24 660 5500 3.3 350 0.13 660 5500
