124
4x
3x
2x
4x
3x
2x
HDP 120
Rn
2
[kN]
n
2
xh
M
2
= 31750 Nm M
2
=25400 Nm M
2
= 21150 Nm M
2
= 15850 Nm
250 000
107.0 107.0 107.0 107.0
107.0 107.0 107.0 107.0
500 000
88.0 95.1 99.9 105.8
88.1 101.5 107.0 107.0
750 000
73.9 81.0 85.7 91.6
69.6 83.8 92.5 97.1
1 000 000
62.5 71.9 76.6 82.6
57.6 72.4 81.3 88.1
1 250 000
52.8 65.4 70.2 76.1
48.8 64.0 73.3 81.5
2 500 000
23.7 43.9 52.5 58.5
23.0 40.6 50.8 62.2
3 750 000
— 30.4 42.6 49.7
— 28.1 39.2 51.4
5 000 000
— — 34.2 44.2
— — 31.7 44.3
HDP 120
Rn
2
[kN]
n
2
xh M
2
= 31750 Nm M
2
= 25400 Nm M
2
= 21150 Nm M
2
= 15850 Nm
250 000
88.9 101.5 107.0 107.0
100.7 107.0 107.0 107.0
500 000
60.3 73.0 81.4 91.9
72.2 82.5 89.3 97.9
750 000
46.1 58.8 67.3 77.8
58.0 68.3 75.2 83.7
1 000 000
37.0 49.7 58.2 68.8
48.9 59.3 66.2 74.7
1 250 000
30.5 43.2 51.7 62.3
42.4 52.8 59.6 68.2
2 500 000
— 25.5 34.0 44.6
— 35.1 42.0 50.6
3 750 000
— — 25.3 35.9
— 26.3 33.2 41.8
5 000 000
— — — 30.3
— — 27.7 36.2
Albero al quale sono riferiti i carichi radiali
ammissibili. Per gli alberi bisporgenti il cari
-
co può essere applicato solo sull’estremità
così evidenziata. In caso diverso consultare
il Servizio Tecnico Bonfiglioli.
Welle, auf die sich die zulässigen Radialkräfte
beziehen. Für die Wellen mit zwei Wellenzap
-
fen kann die Kraft nur auf das so gekenn
-
zeichnete Wellenende ausgeübt werden. An
-
dernfalls mit dem technischen Kundendienst
von Bonfiglioli Rücksprache halten.
h: durata in ore riferita al cuscinetto dell'albero
lento.
h: expected lifetime [hours] for bearing of the
output shaft.
h: Lebensdauer in Stunden für das Lager der
Abtriebswelle.
Shaft the rated overhung load is applicable to.
For double extended shaft the load is only ap
-
plicable to the extension highlighted Should
this not be the case consult Bonfiglioli’s Tech
-
nical Service.
(—) Consultare il Servizio Tecnico Bonfiglioli (—) Contact the Bonfiglioli Technical Service. (—) Bitte wenden Sie sich an den technischen
Kundendienst von Bonfiglioli.
SH
SH
LP
LP
