135
4x
3x
2x
HDP 100
An
2
[kN]
n
2
xh
M
2
= 20000 Nm
M
2
= 16000 Nm
M
2
= 13300 Nm
M
2
= 10000 Nm
250 000
a
40.0 40.0 40.0 40.0
b
40.0 40.0 40.0 40.0
c
40.0 40.0 40.0 40.0
d
40.0 40.0 40.0 40.0
500 000
a
40.0 40.0 40.0 40.0
b
40.0 40.0 40.0 40.0
c
40.0 40.0 40.0 40.0
d
40.0 40.0 40.0 40.0
750 000
a
40.0 40.0 40.0 40.0
b
35.2 40.0 40.0 40.0
c
40.0 40.0 40.0 40.0
d
32.4 40.0 40.0 40.0
1 000 000
a
40.0 40.0 40.0 40.0
b
26.5 40.0 40.0 40.0
c
40.0 40.0 40.0 40.0
d
23.6 38.2 40.0 40.0
1 250 000
a
40.0 40.0 40.0 40.0
b
20.3 34.3 40.0 40.0
c
40.0 40.0 40.0 40.0
d
17.4 32.0 40.0 40.0
2 500 000
a
— 40.0 40.0 40.0
b
— 17.3 26.8 38.3
c
— 40.0 40.0 40.0
d
— 15.0 24.9 36.9
3 750 000
a
— 40.0 40.0 40.0
b
— 8.9 18.4 29.9
c
— 40.0 40.0 40.0
d
— — 16.5 28.5
5 000 000
a
— 40.0 40.0 40.0
b
— — 13.0 24.5
c
— 40.0 40.0 40.0
d
— — 11.1 23.1
verso di rotazione albero lento
verso di applicazione del carico as
-
siale
direction of rotation of output shaft
direction of application of axial force
Drehrichtung der Abtriebswelle
Wirkrichtung der Axialkraft
(—) Consultare il Servizio Tecnico Bonfiglioli (—) Contact the Bonfiglioli Technical Service. (—) Bitte wenden Sie sich an den technischen
Kundendienst von Bonfiglioli.
SHLP
