BONFIGLIOLI HDP Series User Manual

139
4x
3x
2x
HDP 140
An
2
[kN]
n
2
xh
M
2
= 67200 Nm
M
2
= 53750 Nm
M
2
= 44800 Nm
M
2
= 33600 Nm
250 000
a
95.0 95.0 95.0 95.0
b
95.0 95.0 95.0 95.0
c
95.0 95.0 95.0 95.0
d
95.0 95.0 95.0 95.0
500 000
a
83.9 95.0 95.0 95.0
b
95.0 95.0 95.0 95.0
c
79.1 95.0 95.0 95.0
d
95.0 95.0 95.0 95.0
750 000
a
83.9 95.0 95.0 95.0
b
95.0 95.0 95.0 95.0
c
79.1 95.0 95.0 95.0
d
95.0 95.0 95.0 95.0
1 000 000
a
64.9 94.1 95.0 95.0
b
95.0 95.0 95.0 95.0
c
60.0 90.2 95.0 95.0
d
95.0 95.0 95.0 95.0
1 250 000
a
51.3 80.4 95.0 95.0
b
95.0 95.0 95.0 95.0
c
46.3 76.5 95.0 95.0
d
95.0 95.0 95.0 95.0
2 500 000
a
— 43.5 62.8 87.1
b
95.0 95.0 95.0 95.0
c
— 39.5 59.6 84.7
d
95.0 95.0 95.0 95.0
3 750 000
a
— 25.2 44.5 68.8
b
— 95.0 95.0 95.0
c
— 21.2 41.2 66.4
d
— 95.0 95.0 95.0
5 000 000
a
— — 32.8 57.1
b
— 89.2 95.0 95.0
c
— — 29.6 54.6
d
— 83.8 91.4 95.0
verso di rotazione albero lento
verso di applicazione del carico as
-
siale
direction of rotation of output shaft
direction of application of axial force
Drehrichtung der Abtriebswelle
Wirkrichtung der Axialkraft
(—) Consultare il Servizio Tecnico Bonfiglioli (—) Contact the Bonfiglioli Technical Service. (—) Bitte wenden Sie sich an den technischen
Kundendienst von Bonfiglioli.
