46
—
Verica termica non necessaria / Thermal verication not necessary / Wärmeprüfung nicht erforderlich
*
HDP 60 n
1
= 1750 min
-1
Tamb = 20°C Tamb = 40°C
i n
2
Mn
2
Pn
1
P
T
P
TFANL / R
P
TSR
P
T
P
TFANL / R
P
TSR
[min
-1
] [Nm] [kW] [kW] [kW] [kW] [kW] [kW] [kW]
HDP 60 2 7.1 245 3900 104 * * 75 * * *
HDP 60 2 8.0 218 4000 95 * * 75 * * *
HDP 60 2 9.0 195 4200 89 * * 75 * * *
HDP 60 2 10.1 174 4250 80 * 68 75 * * 62
HDP 60 2 11.2 157 4500 77 * 68 75 * * 62
HDP 60 2 12.5 140 4600 70 52 68 — 34 48 62
HDP 60 2 13.5 129 4800 68 52 — — 34 48 62
HDP 60 2 15.2 115 4600 58 52 — — 34 48 —
HDP 60 2 17.3 101 4750 52 52 — — 34 48 —
HDP 60 2 19.4 90 4600 45 — — — 34 — —
HDP 60 3 22.7 77 4050 35 33 — — 21 31 —
HDP 60 3 25.5 69 4200 32 — — — 21 31 —
HDP 60 3 28.2 62 4500 31 — — — 21 31 —
HDP 60 3 31.7 55 4350 27 — — — 21 — —
HDP 60 3 34.2 51 4700 27 — — — 21 — —
HDP 60 3 38.5 45 4600 23 — — — 21 — —
HDP 60 3 43.7 40 4900 22 — — — 21 — —
HDP 60 3 49.1 36 4600 18.2 — — — — — —
HDP 60 3 56.6 31 4800 16.5 — — — — — —
HDP 60 3 63.6 27.5 4600 14.1 — — — — — —
HDP 60 3 68.6 25.5 5000 14.2 — — — — — —
HDP 60 3 77.1 22.7 4600 11.6 — — — — — —
HDP 60 3 87.6 20.0 5000 11.1 — — — — — —
HDP 60 3 98.4 17.8 4600 9.1 — — — — — —
4.1 - POTENZA TERMICA
E DATI TECNICI
4.1 - THERMAL CAPACITY
AND RATING CHARTS
4.1 - WARMELEISTUNG
UND AUSWAHLTABELLEN
P
T
Potenza termica complessiva Overall thermal capacity Gesamtwärmeleistung
P
TFAN...
Potenza termica comprensiva del contri-
buto fornito dalla ventilazione forzata
Thermal capacity with the contribution of
forced ventilation
Wärmeleistung einschließlich des Beitrags
durch die Zwangsbelüftung
P
TSR
Potenza termica comprensiva del contri-
buto fornito dalla serpentina di raffredda-
mento
Thermal capacity inclusive of contribution
from cooling coil
Wärmeleistung einschließlich des Bei-
trags durch die Kühlschlange
P
TMCRA...
Potenza termica comprensiva del contri-
buto fornito dalla centralina di raffredda-
mento con scambiatore aria/olio
Thermal capacity inclusive of contribution
from air/oil exchanger cooling unit
Wärmeleistung einschließlich des Bei-
trags durch das Kühlaggregat mit
Luft-/Öl-Wärmetauscher
P
TMCRW...
Potenza termica comprensiva del contri-
buto fornito dalla centralina di raffredda-
mento con scambiatore acqua/olio
Thermal capacity inclusive of contribution
from water/oil exchanger cooling unit
Wärmeleistung einschließlich des Bei-
trags durch das Kühlaggregat mit
Wasser-/Öl-Wärmetauscher
