BONFIGLIOLI Vectron Syn10 T400 05 AF

20
20
SYN10 S 220 07/09 SY
N
10 T 400 05/07/09
Model
Dimension
A
143.1 127.5
B
140
C D
8.0
S220 07/09 e T400
171.7
E
108
F
118
G
Unit :mm
S220 07/09 e T400
M4
( )
NOTE:
For safety reason, we strongly recommend
users to remove the M4 grounding screw
then screw the enclosed "metal frame
grounding terminal" on the same location to
make a grounding bar to ensure good earth
protection.
q
See NOTE
Mounting Instructions
Model
Dimension
3xø4.5
