5. Dimensions & Location of terminal block
SYN10 S 115 01/03/05, S 220 01/03/05:
Unit: mm
MODEL/DIMENSIONS A B C D E F G
SYN10 S 115 e
220 01/03/05
132 116 130 8.2 118 61 72
See NOTE
NOTE:
For safety reason, we strongly recommend
users to remove the M4 grounding screw
then screw the enclosed "metal frame
grounding terminal" on the same location to
make a grounding bar to ensure good earth
protection.
