bora Classic 2.0 Installation Instructions

EN
13
Technical data
www.bora.com
Device dimensions CKCB
R3
327
515 235 140
Fig. 3.17 CKCB device dimensions top view
7
300
240
43,5
13,5
75
45
Fig. 3.18 CKCB device dimensions front view
491
480
12
17,5
Fig. 3.19 CKCB device dimensions side view
3.6 CKCB
Parameter Value
Supply voltage 220 - 240 V
Frequency 50/60 Hz
Power consumption 3.68 kW
Fuse protection 1 x 16 A
Dimensions
(width x depth x height)
327 x 515 x 75 mm
Weight
(incl. accessories/packaging)
7.4 kg
Cooktop
Power levels 1-9, 2-ring connection, roaster
cooking zone connection
Warming levels 3
Front cooking zone (zone 1) Ø 180 mm 1600 W
Rear cooking zone (zone 2)
2-ring connection, roaster
cooking zone connection
Ø 120 mm
Ø 180 mm
Ø 180 x 410 mm
600 W
1600 W
3680 W
Cooktop energy consumption
Front cooking zone (zone 1) Ø 180 mm 193.4 (Wh/
kg)
Rear cooking zone (zone 2) Ø 120/180 mm
Ø 180 x 410 mm
195.5 (Wh/
kg)
Total (average) 194.4 (Wh/
kg)
Tab. 3.6 Technical data CKCB

bora Classic 2.0 Specifications

General

Product name	BORA Classic 2.0
Category	Cooktop
Cooking zones	2
Automatic heat up function	Yes
Timer function	Yes
Child safety lock	Yes
Residual heat indicator	Yes
Material	Glass ceramic
Color	Black
Type	Induction
Control type	Touch
Power levels	9
Extraction System	Integrated
Frequency	50 Hz
Safety features	Overheating protection
Supply voltage	220 – 240 V
Installation type	Built-in
