18
1. Attaching the toe kick panel
Note:
Risk of damage to the appliance. Do not cover ventilation
slots in the base panel.
Nominal dimensions to be observed:
Stainless steel panel (accessory)
1. Attach the base panel to the appliance (do not
screw on).
2. Remove the protective film from the adhesive pads.
3. Fit the toe kick panel to the base panel and press
firmly into place.
Wooden panel
1. If required, shorten wooden panel to the required
length.
2. Screw wooden panel to the base panel from behind.
There are already screw holes in the base panel.
2. Aligning the base panel
1. Put on the base panel (do not screw on) and
measure the difference in depth A between the base
panel and toe kick panel of the adjacent cabinet.
2. Remove the base panel.
3. Adjust the brackets (a) to the dimensions A and
tighten.
4. Attach the base panel.
