Bosch B5512 Reference Guide

19.2.7 [3] RF Diagnostic Menu > [1] RF Points 137
19.2.8 [3] RF Diagnostic Menu > [2] RF Repeater Menu 138
19.3 [3] Diags menu 139
19.3.1 [1] Wireless 139
19.3.2 [2] Network menu 139
19.3.3 [3] Cellular menu 140
19.3.4 [4] IP Camera 140
19.4 [4] Serv Byp (Service Bypass) menu 141
19.5 [5] Versions menu 141
19.6 [6] Cloud menu 143
19.6.1 [1] Setup 143
19.6.2 [2] Status 144
20
Specifications 145
20.1 Wire requirements 147
21
Reporting and device number information 148
21.1 Report format definitions 148
21.2 SDI2 address information 156
21.3 Device numbers (zzz, dddd) 157
21.4 Communication Trouble device numbers (zzzz) 157
21.5 Special User IDs (uuuu, iiii) 157
21.6 Keypad alarm virtual point numbers (ppp, pppp) 158
Control Panel Table of Contents | en 7
Bosch Security Systems, Inc. Installation and System Reference Guide 2015.07 | 12 | F.01U.287.180

Bosch B5512 Specifications

General

Model	B5512
Category	Control Panel
Zones	48
Partitions	4
Series	B Series
Wired Zones	48
Programmable Outputs	2
On-board Relays	1
Keypads Supported	8
Manufacturer	Bosch
Input Voltage	16.5 VAC
Battery Backup	12 VDC, 7 Ah
Outputs	2
Communication Formats	Contact ID, SIA
Communication	Cellular
Power Supply	16.5 VAC
