Approved applications
The UL System Chart references the components that are evaluated and listed by UL for
compatibility with B5512/B4512/B3512 control panels. These components meet the basic
system requirements for the applicable standard.
Refer to Compatible UL listed components, page 95.
The system wiring diagrams show the relationship between the control panel and the
accessory components.
Refer to System wiring diagrams, page 79.
Optional compatible equipment
You can use UL Listed components not requiring evaluation for electrical compatibility in many
applications when installed according to the manufacturer’s instructions.
Burglar applications
You can use UL Listed components not requiring evaluation for electrical compatibility in
burglary applications. In some cases, you must use a UL Listed interface module with the
sensors. Consult the individual component specification and installation documents to
determine suitability.
Bank safe and vault applications
You must use the D8108A Attack-Resistant Enclosure to meet UL Standard 681.
Refer to Wiring information for installations using the Rothenbuhler 5110/4001-42 High Security
Bell, page 91 for wiring instructions and diagrams.
Control panel enclosure requirements
UL Standard 681 for Installation and Classification of Mercantile and Bank Burglary Alarm
Systems requires foil lining or equivalent protection of the control unit enclosure. The D8108A
Attack-Resistant Enclosure does not have a foil lining, but acceptable protection is provided by
mounting electronic vibration sensors inside the enclosure.
Notice!
Do not use proximity alarms (capacitance) to protect the control panel enclosure.
Install the same electronic vibration sensors in the D8108A that are used to protect the
safe or vault.
Mount the Sentrol 5402, Potter EVD-S, or Arrowhead S-3810 electronic vibration
detection (EVD) system inside the D8108A to meet the UL 681 requirements.
Install and test the EVD sensor according to the manufacturer’s instructions.
Mount the EVD sensor directly inside the metal cabinet of the D8108A.
!
Caution!
Do not install the EVD sensor within 6.4 mm (0.25 in) of the components or traces of the
printed circuit assembly.
Battery connections
Using a D122 Dual Battery Harness, connect two 12 V 7 Ah batteries in the control panel
enclosure.
Use a separate D8108A for the two 12 V 7 Ah batteries. When using a D122L Dual Battery
Harness, wire the batteries in parallel and connect the harness to the BAT+ and BAT-
terminals of the control panel.
18
18.1
18.1.1
18.1.2
90 en | Approved applications Control Panel
2015.07 | 12 | F.01U.287.180 Installation and System Reference Guide Bosch Security Systems, Inc.
