20 | BEA 070 | Product descriptionen
3.6 LED status
LED1 Status
Off
BEA 070 off
Alternate orange and green
flashing at one-second intervals
BEA 070 on and ready
for operation
Rapid alternate orange and
green flashing
USB or Bluetooth commun-
ication with Bosch Emissions
Analysis software
Rapid alternate orange and
green flashing (Bosch Emissions
Analysis software not started)
Defective firmware
Red light
BEA 070 defective
LED2 (only with battery pack
special accessory)
Status
Off
BEA 070 off
Green flashing at one-second
intervals
Battery capacity between
80 % and 100 %
Orange flashing at one-second
intervals
Battery capacity between
10 % and 80 %
Red flashing at one-second
intervals
Battery capacity less than
10 %
Green light Battery capacity between
80 % and 100 % (supply
via power supply unit or
charging station)
Orange light Battery capacity less than
80% (supply via power
supply unit or charging
station)
Rapid green flashing Maintenance mode
Red light Problem
3.7 Bluetooth
3.7.1 Bluetooth USB adapter
Only the Bluetooth USB adapter included in the scope of
delivery enables a wireless connection to the BEA 070. It
is plugged into the PC/laptop. Readiness for operation is
indicated by the flashing blue LED.
! It is not possible to operate any other item of Blue-
tooth hardware fitted or plugged into the PC/laptop,
as this would interfere with data communication
between the BEA 070 and the PC/laptop.
! Do not subject the Bluetooth USB adapter connected
to the laptop to mechanical strain or use it as a
handle, as this could damage the laptop or Bluetooth
USB adapter.
i The USB connection has precedence in the case of
simultaneous USB and Bluetooth connection.
3.7.2 Notes on Bluetooth Manager symbol
Bluetooth Manager symbol (in task bar):
Color Function
Green
Bluetooth USB adapter active and
communicating with BEA 070.
White Bluetooth USB adapter plugged into PC/laptop
but Bluetooth connection not active.
White/green
at 7-second
intervals
Bluetooth USB adapter attempting to establish
wireless connection to BEA 070.
Red Bluetooth USB adapter not plugged into
PC/laptop.
3.7.3 Information on errors
i Heed the information given in Section 2.4 in the event
of Bluetooth transmission problems during exhaust gas
measurement.
No communication between BEA 070 and PC/laptop
Possible causes Action to be taken
No power supply.
Check whether BEA 070 is being supplied
with voltage (power supply unit or
vehicle battery).
BEA 070 not
active or incorrectly
configured.
1. Start CDC:
"Start >> All Programs >> Bosch >>
Diagnostics >> Central Device Com-
munication" or left-click on " " in the
task bar.
2. Check type of connection in CDC:
"Settings >> Device interfaces"
Group: RTM
Device type: BEA 070
Connection: USB/BTB (Bluetooth)
Problem with
Bluetooth
connection or no
connection (e.g.
after PC/laptop has
been on standby).
Bluetooth Manager symbol white,
flashing white/green or red.
1. Reduce distance between Bluetooth USB
adapter and BEA 070.
2. If the Bluetooth USB adapter is to be
used at various PC/laptop USB ports,
the Bluetooth driver must be installed
for each USB port.
3. Initialize Bluetooth driver if the
Bluetooth connection is not OK on
testing (see Section 3.6.4).
4. Unplug the Bluetooth USB adapter and
plug in again or reboot the PC/laptop.
No Bluetooth USB
adapter.
Bluetooth Manager symbol red
1. Plug in Bluetooth USB adapter.
2. Restart exhaust gas measurement.
