Analog and Frequency Inputs | 5
Bosch Motorsport Data Logger C 70 Manual 27/112
Choose device
Choose input source
(internal/external)
Choose driven axle
Choose individual wheel
speed channels
Set limit for speed
difference for calculation
4. Click ‘Finish’ when done.
The speed calculation is inserted into the C 70 Project Tree.
Speed calculation
in DDU Project
Tree
Measurement
channels
calculated speed
and calculated
distance
Configuration
window
