Starting up | 11
Bosch Motorsport Data Logger C 70 Manual 51/112
11 Starting up
11.1 Before starting
Install the software required C 70 operation. It is developed for Windows system software.
Following software versions are used in this manual:
– C 70 setup, configuration and calibration: RaceCon
– Measurement data analysis: WinDarab V7
Set up the 100 Mbit Ethernet connection to the C 70.
– The Ethernet port has ‘cable auto crossover’ functionality
11.1.1 Setting up a new RaceCon Project
The following screenshot shows an overview of the RaceCon Main Screen with its areas.
All (sub-) windows are resizable and dockable. You can find them under the ‘Windows’
tab.
Project
Tree
Data Area
Message Area
Main Area
Toolbox
1. Start the RaceCon software.
