Technical Data | 8
Bosch Motorsport Data Logger C 70 Manual 45/112
8 Technical Data
The data logger C70 integrates a programmable data logging system for motorsport ap-
plications for a very competitive price. Additional input devices can be connected via Eth-
ernet and CAN buses.
Data Analysis Software WinDarab is available free of charge as “WinDarab V7 free” on our
website. The logger can be upgraded to a 2
nd
logging partition of 1 GB (e.g. for long term
recording).
For quick data transfer from the car e.g. during pit stop, data copy to a USB stick is avail-
able as an option. The stick is connected to the wiring harness for the C70.
The device comes with 4 analogue and 4 speed inputs as standard; further 12 analogue
inputs are available as optional upgrade.
Processor 667 MHz Dual Core
Converters 8 kHz AD converters with digital low pass
filter
Internal power source Li/Ion capacitor
Configurable math channels
User configurable CAN in/out messages
Sampling rate Max. 1 ms
Online data compression
Logging rate Max. 600 kB/s
Recording channels 1,040
Logged data download speed Max. 1,000 kB/s
Internal storage capacity 3 GB (standard), plus 1 GB (optional)
LTE Ethernet telemetry support, GSM telemetry support
RS232 for GPS and telemetry
CCP-Master, data acquisition from ECU that support CAN calibration protocol (optional)
CAN interfaces 2
Ethernet 100BaseT 2
Laptrigger input 1
