8 | Technical Data
46/112 Data Logger C 70 Manual Bosch Motorsport
RS232 Telemetry, GPS
Configuration via RaceCon Over Ethernet or MSA-Box II
Mechanical Data
Size 151 x 126 x 25.5 mm
Weight 450 g
Protection Classification IP54 to DIN 40050, Section 9, Issue 2008
Operating temperature internal -20 to 85°C
Max. vibration Vibration profile 1 (see Appendix or
www.bosch-motorsport.com)
Electrical Data
Supply voltage 5 to 18 V
Inputs
Analog channels 4 standard, additional 12 optional
Input range 0 to 5 V
Resolution 12 bit
Switchable pull up resistor For all ANA_IN
Wheel speed inputs 4 Hall-effect or DF11, switchable
Outputs
Sensor supply 5 V ± 1 % (250mA) 2
Sensor supply 10 V ± 1 % (250mA) 1
Sensor supply U_Bat 250 mA 1
Sensor ground 4
Optional Upgrades
USB_DATA USB-Port unlocked (Rugged USB flash
drive Bosch File System (BFS) format in-
cluded, works with Bosch File System
(BFS) preformatted USB Flash drive only)
Adapter cable to USB-Port included in Upgrade USB_DATA
Adapter for wiring harness included in Upgrade USB_DATA
CCP_MASTER CCP-Master (ASAP2 file from ECU manu-
facturer required
ETHER_TELE LTE Ethernet Telemetry
FULL_LOG_2 Enable full logging performance of 1 GB
partition 2
I_O EXTENS Enable additional 12 analog input chan-
nels
Connectors and Wires
Motorsport connector on logger AS-216-35 PN
