Starting up | 11
Bosch Motorsport Data Logger C 70 Manual 57/112
11.3 First recording (Quick Start)
This chapter explains the configuration of the recording of the battery voltage channel.
See chapter ‘Recording [}73]’ for a detailed instruction to configure recordings.
1. Click on the ‘Logger’ tab to go to the page ‘Logger’.
2. Use the search bar in the ‘Data’ window, to search for ‘ub’ (measurement channel for
battery voltage).
3. Drag and drop the ‘ub’ measurement channel into the recording area.
4. Click on the ‘Download’ button in the upper left corner.
The configuration download starts and the C 70 carries out a reset.
Now you can find the ‘ub’ measurement channel in the ‘Data Area’.
