18
Subject to change without prior notice Revised 05-12
6 720 220 048
CE Series
Figure 11: Cooling Tower/Boiler Application
COOLING TOWER/BOILER APPLICATION
1. LINE VOLTAGE DISCONNECT (UNIT)
2. LOW VOLTAGE CONTROL CONNECTION
3. P/T PLUGS (Optional)
4. HOSE KITS (Optional)
5. BALL VALVES
6. SUPPLY AND RETURN LINES OF CENTRAL SYSTEM
7. FLEX DUCT CONNECTION
8. HANGING BRACKETS ASSEMBLY
9. THREADED ROD
10. HANGING BRACKET ASSEMBLY ES048 and up #930-006
NOTE: SEE FIGURE #3 FOR CONDENSATE DRAIN CONNECTION
Cooling Tower/Boiler Application
